DRAW FRAME: FA316A

Main technical parameters
Product evaluation

Inquire Now

Main technical parameters

Material	Cotton, manmade fiber, blends, fiber length10-80 mm
No. of Delivery	2 (Double coiler)
Doubling	Up to 8
No. of Feeding End	6-8,draft:4-11
Drafting Type	3 over 3 with pressure bar and guide roller
Loading Type	Pendulum arm spring weighting.
Delivered Sliver Weight (Ktex)	1.25-7
Deliver Speed	2.47-10 m/s(200-600 m/min)
Feed Can Diameter	Φ400.Φ500,Φ600 height:1100(900)mm.
Delivery Can Diameter	Ф300,Ф350,Ф400,Ф500 mm ,height: 1000(900) mm.

Max. Delivery Speed

1100 m/min

Automaticflter cleaningCentral drafting system setting without gaugesAutomatic can changerEmpty can feed for up to 3 reserve cansCentral lubricating stripControl panel with graphic display
Control System	The speed of main motor is controlled byInverter. PLC is adopted for controlling system.
Auto Stop Motion	Photoelectric stop and micro switch stopmotion. Motors: main motor, can changemotor, servo motor, suction motor, cleaningmotor. Stop motion electric stop motion forbreakage on top roller & calendar roller,electric stop motion for choke of sliver atgatherer & coiler tube; sliver length stopmotion actuated by auto reset counter,electric stop motion for creel part.
Power	3-phase ac, 380v/50Hz.
