Auto High Precision Roller Grinding Machine TDM-KSB

main feature :

The Auto High Precision Roller Grinding Machine TDM-KSB is composed of twelve primary categories of parts, including frame parts, transverse parts, feeding parts, clamp parts, loading and unloading parts, grinding parts, transmission parts, feeding parts, collecting parts, and feeding box parts, as well as auxiliary parts.

-1

Product details

Integrated material box, automatic connection of feeding and unwinding.

100 sets of loading box storage, 120 sets of loading box storage.

Automatic detection, automatic polishing after setting the polishing size

Automatic dressing of the grinding wheel, automatic cleaning of the grinding wheel.

PLC program automatic control.


Main technical parameters

Installed power: about 5.5Kw

Grinding diameter range: Φ20-40mm,≤190mm

Maximum workload per hour: about 300set

Grinding precision: ≤0.02mm

Sharpened: Ra:0.3-0.8um
