| Overall size(L*W*H) | 5900x2000x3000mm |
| Working width | 1500mm |
| Cotton feeding weight | 400 ~1000 kg/hour |
| Equipment weigh | 3t |
| Power of the whole machine | About 3.7KW |
| Inclined curtain is conversion driven by a separate motor | 0.75KW(controlled by frequency) |
| Hair homogenizing roller and wiper rolle | 2.2KW(driven by the same motor) |
| Conveyor curtain is conversion driven by a separate motor | 0.75kw(controlled by frequency) |
FAQ
Q1: What material can the BGO01 batching feeder handle?
A1: The machine is intended for baled fibre after preliminary opening. Wool and suitablechemical fibres can be evaluated according to fibre length, fineness, bulk density, moisture
level and tuft condition.
Q2: Does the BGO01 include an automatic weighing unit?
A2: The published machine data describes adjustable apron feeding but does not list load-cellweighing or batching accuracy. If a project needs recipe weighing, batching tolerance or multi-
component dosing, these functions should be confirmed in the technical agreement.
Q3: What information is needed for a BGO01 quotation?
A3: Please provide the fibre type, bale condition, fibre length, material density, planned
proportions, required hourly capacity, upstream opener, downstream equipment, feeding
height, voltage, frequency and workshop dimensions.
Product Advantages
1.1. Adjustable Fibre Feeding Rate
The inclined apron and delivery apron use independent variable-frequency drives. Their speeds can be adjusted to match the fibre condition and the operating rate of the connected machinery.
2.2. Fibre Layer Equalizing
The equalizing roller works with the inclined apron to manage the thickness of the fibre layer. This arrangement helps limit large feed fluctuations during continuous operation.
3.3. Suitable for Pre-Opened Baled Fibre
The BGO01 is intended for baled fibre that has received preliminary opening. It can be used in wool and suitable chemical-fibre preparation lines according to the confirmed material data.
4. 4.Wide Capacity Adjustment
The stated feeding range is 400–1,000 kg/h. The operating rate can be planned according to the material condition, production target and capacity of the next machine.
5. 5.Coordinated Drive Arrangement
The inclined apron, equalizing section and delivery apron use coordinated drive units. This layout supports controlled fibre transfer through the different working sections of the machine.
