Computerized Chain Stitch Multi-needle Quilting Machine TD-W-SJS

main feature :

The Computerized Chain Stitch Multi-needle Quilting Machine TD-W-SJS boasts a new retainer frame structure for reduced noise. It offers improved speed and production, with adjustable press plate lifting for different material thickness. The machine features automatic thread breaking detection, needle lifting, and CNC speed adjustment. Other key benefits include high rigidity, low vibration and noise, and a new generation CNC system for precise quilting. The machine also offers pattern combining and multi-span quilting for quilting different patterns on mattresses of different sizes. It comes with a fault detection function, easy CAD drawing preparation, and a CE certificate.


-2_0000_2
-2_0001_1

Product details

New type retainer frame structure,with the advantages of low noise. Optimized the mechanical structure make the higher speed and more production. Press plate lifting can be adjusted by one-button accordirng to different material thickness.

More tight thread stitches make the quilting pattern with strongger third dimension. Needle bar and press plate are controlled by a doubles -wingin9 device without cam avoiding lubrication and dirtying of materiaLà Multi-span and independent patterns (360°, 180° patterns are available).

Automatic stop motion control in case the top thread or thebottom thread breaks, automatic needle-lifting and CNC speed adjustment  Outstanding features such as high rigidity,high running speed, low vibration and noise. New generation of CNC system, high precision quilting, dispense with too much parameter adjustment or pattern modification during quilting.

Strong functions of pattern-combining and multi-span quilting to enable you to quilt different patterns in each row in the mattresseof different sizes. Fault detection function for ease of determining the running state of the machine at any given time. Easy preparation of CAD drawings extremely precise. CE certificate.

Main technical parameters

Size (LWH):

4700×1560×2100 mm

Quilting width:

 2550 mm

Space between needle rows:

50.8,76.2,127 ( 5")

Space between needle rows:

76.2,76.2,76.2,152.4 ( 6")

Space between needles:

25.4 mm

X-axis movement displacement:

350 mm

Thickness of quilting:

<80 mm for all patterns

Stitch length:

3~8 mm

Speed of operation:

60~300 m/hour

Model of needle:

24/180、23/160、22/140、21/130

Quilting speed:

600~1200 RPM

Total power required:

 7 KW

Voltage:

 380V/50HZ、220V/60HZ

Gross weight:

 5000 KG
