Computerized Lock Stitch Multi-needle Quilting Machiine TD-64-3B, TD-94-3B, TD-112-3B, TD-128-3B

main feature :

The Computerized Lock Stitch Multi-needle Quilting Machine, models TD-64-3B, TD-94-3B, TD-112-3B, and TD-128-3B, feature a cam-free double-swinging device for the needle bar and press plate, ensuring high precision and durability. This design helps minimize lubrication and dirty material issues. The optimized mechanical structure provides a rigid machine body and improved stability, allowing for faster and more stable operation. The material rack separation structure reduces the rack's load effectively. The machine's new press plate adjustment structure makes it simpler to use. It offers multi-span independent patterns, including 360° and 180°, and an advanced up thread-break detection unit. The computerized automatic needle-lifting speed adjustment and new generation CNC system ensure high-precision quilting with minimal parameter adjustment. The machine easily prepares precise CAD drawings and can quilt different patterns in each line on a 3.2m fabric. It can combine patterns strongly. It can also quilt simple embroidery patterns. The fault detecting and indication system enables fast fault correction and return operation.


-2_0000_1

Product details

Needle bar and press plate are connected by camfree dou ble-swinging device, which is with high precision and durable. TThis struc ture can avoid lubrication and dirty material effectively.

Optimized mechanical structure, realizing high rigidity machinee bodyand structure, thus make the machine run faster andmore stable.

Material rack separation structure ,can reduce the loadof the rack effectively.

Adopting the new structure of press plate's adjusting makes tthe machine much simple.

Multi-span independent pattern (360°and 180° patterns areavailable).

Advanced and practical up thread-break detection unit.

Computerized automatic needle-lifting speed adjustment.

New generation of CNC system,advanced machine structurre,high precision quilting,dispense with too much parameter adjustmentor pattern modification during quilting.

Easy preparation of CAD drawing extremely precise.

Different patterns in each line can be quilted on 3.2mfabric and patterns can strongly combine.

Able to quilt simple embroidery patterns.

Fault detecting and indication enabling fast fault correection and return operation.


Main technical parameters

Unit:mm]

HY-64-2B

HY-94-2 B

HY-112-2B

HY-128-2 B

Size (LWH):

3800
1320
1800

4650
1320
1800

5180
1320
1830

5550
1320
1830

Quantity of needle bar:

3

3

3

3

Quilting width:

1600

2400

2850

3250

Space between needle row

76.2,152.4

76.2,152.4

76.2.152.4

76.2,152.4

Space between needles:

25.4

25.4

25.4

25.4

X-axis movement displacer

203.2

304.8

304 8

304.8

Thickness of quilting:

<25

<25

525

<25

Stitch length:

2~5

2~5

2~5

2~5

Speed of production ( m/h

20~120

20~120

20~120

20~120

Model of needle:

16# 19#

16#, 19#

16#. 19#

16#, 19#

Speed of main shaft (RPM

550~750

550~750

500~750

450~650

Total power required:

5KW

5KW

6KW

6KW

Voltage :

380V/50HZ
220V/60HZ

380V/50HZ
220V/60HZ

380V/50HZ
220V/60HZ

380V/50HZ
220V/60HZ

Gross weight:

3200 KG

4200 KG

4500 KG

5000 KG
