High performance Cotton Carding machine

Carding machine

High performance Cotton Carding machine

Cotton carding machine FA1213A

main feature :

The Cotton Carding Machine FA1213A offers an optimal balance between quality and production capacity. It features a new detecting and protecting system, mixed loop auto-leveller system, and high-quality carding system. The modular design ensures easy operation and maintenance.

-2_0004_776775FF0E59C76AC653A6EBF7FE1514
20231222-084856.246-5
20231222-084856.246-2
20231222-084856.246-7
20231222-084856.246-8
20231222-084856.246-9

Product details

The carding arc length decides the quality. Longest carding arc lerngth of 2.8 meters ensures best quality.

Mono-block casting iron cylinder, doffer and side wall  ensures good stability and low thermal expansion  coefficient. The carding technical gauge is stable even  when machine runs at high speed, ensuring the high  production.

The stepped entity frame welded by steel plate is  characterized by its flexible mechanism and its special  processing technology, ensuring the major gauge stable  and uniform.


  •



    FA1213 Carding machine with high production and efficiency, the carding arc length decides the quality, Longest carding arc length of 2.8meters ensures best quality.

  •



    Modular design-easy operation and maintenance and Modular design realizes flexible replacement to meet different technical requirements based on various material and guarantees excellent product.

  •



    New type mixed loop auto-levelled system and new type detecting and protecting system. New type detecting and protecting system, metal detecting device to deduct metal during cotton feeding.

Main technical parameters

type

FA1213

Application

Application applicable to chemical fiber,pure cotton in length from
22~76mm and other blended material

Max. Actual output (kg/h)

160

Max. Sliver delivery speed (meter/min)

320

Sliver count(g/m)

3.5~10

Feed weight(gram/meter)

400~1300

Working width(mm)

1280

Total draft folds

38~370

Licker-in working diameter(mm)

Ф 250

Licker-in working diameter(mm)

706

Doffer working diameter(mm)

4.3~84

Doffer working speed(rpm)

Ф 1288

Cylinder working diameter(mm)

347~477

Cylinder working speed(rpm)

30/84

Pieces of rotary
(working flat/total flats)

70~408

Attached
carding
segments

Licker-in carding segment

2(Pieces)

Front stationery flats

8(Pieces)

Back stationery flats

10根

Web cleaner

Front 3, Back 3

Pieces (Cotton)

Front 2, Back 2

(Cotton)

Continuous air suction volume(m³/hour)


(Chemical fiber)

Statistic pressure at exit(pa)


4200

Compressed air pressure (kg/c㎡)


-800

Compressed air consumption(m³/h)


6~7

Total power installation(KW)


0.5

Safety cover type


13.79Totally enclosed

Land occupation (Lx W)(mm)


5825X2480x3720 (Ф 1000)

Machine net weight(kg)


About8000
