Needle type | Latch needle |
Gauge | E18 E22 E24 |
Working width | 100 inches,138 inches,210 inches |
Guide Bar No. | 5 |
Double pile height | 2-12mm |
Main drive | Oil-immersed cam,Eccentric linkage |
Max speed | 850 rpm |
Pattern drive | N-pattern drive,chain link or pattern disk(Optional: Electronic Control) |
Yarn let-off device | EBC Electronic yarn let-off |
Fabric take-up | Electronic take-up |
Batching device | Independent batching device |
Main motor power | 7.5 kw |
FAQ
Q1: What fabrics can the TD-D5 Raschel machine produce?
A1: The TD-D5 can produce short-pile textiles, sandwich mesh and 3D spacer fabrics. Typical uses include car seat material, mattress mesh, sofa upholstery, blankets, curtains, shoe material and apparel components.
Q2: What working widths and gauges are available?
A2: Published TD-D5 data lists working widths of 100, 138 and 210 inches, equal to approximately 254, 351 and 533 cm. Available machine gauges are E18, E22 and E24.
Q3: What information is needed for a TD-D5 machine proposal?
A3: Please provide the yarn material, yarn count, machine gauge, fabric width, fabric weight, pile height or spacer distance, lapping plan and planned daily output. Local voltage, frequency, ambient temperature and workshop dimensions should also be provided.
Product Advantages
1.Five-Guide-Bar Arrangement
Five guide bars provide separate yarn paths for ground, pile and connecting yarns. The lapping plan can be arranged according to the required short-pile or spacer fabric structure.
2.EBC Electronic Yarn Let-Off
EBC electronic yarn let-off manages yarn delivery during knitting. This supports coordinated yarn feeding across different guide bars and warp beam groups.
3.Electronic Fabric Handling
Electronic fabric take-up controls fabric movement according to the knitting process. An independent batching unit collects the knitted material after take-up.
4.Laser Yarn-Break Monitoring
The laser yarn-break detector monitors yarn movement. When a broken yarn is detected, the machine can stop so that the operator can locate and handle the affected position.
5.Maintenance Access
The fixed trick plate supports fabric formation. The swing-away sinker bed provides working access during latch-needle inspection and replacement.
