Gauge | 7G、9G、10G、12G、12G、14G、16G |
| Knitting width | 36,52,72,80inch |
| Knitting system | Two system or Three system |
| Knitting speed | Controlled by servo motor with 64 sections optional, Max 1.55M/S.The serve motor combines precise feedback control system with high-speed digital motor combines precise feedbacck control system with high-speed digital output |
| Knitting function | Jacquard, hanging eyes, flipping needles, same mouth weavinig and hanging,same mouth flipping, picking holes, visible and hidden needles, etc. |
| Racking | Controlled by servo-motor racking within 2 inches and withfine adjusting function. |
| Stitch density | Controlled by stepping motor, 64 section stitch select-able adjustable scope supported by subdivision technology: 0-500, the stitch of the knitwear can be accurately controlled. |
| Transfer system | Triangle composite design, capable of performing needle flipping anad joining functions at the same mouth, thereby improving production efficiency. |
| HangingFunction | Triangle composite design, capable of performing weaving, lifting, and noIn wea-ving functions at the same mouth, thereby improving production efficiency |
| Take-downsystem | Infrared alarm,Computer programs instruction, stepper motor contre01,64-stagetension selection with an adjustable range between:0-100. |
| Color-changing system | 2x8 yarn feeders on each side of 4 guide rails, shift able on aany needle position |
| Protection system | The machine will automatically alarm if yarn-breaking, knots, floatting yarn, rewind, end of knitting, fail of racking needle breakage, error programming occur, also set up the safety auto-lock protect device |
| Network function | High speed network can coordinate up to 250 machines; the knitting data can be uploaded downloaded and shared. |
| Power supply | Single-phase 110V/220V/three-phase 380V,adopt advanced CMOStechnology, having memorizing function at power shock stop.(Optiona British plug) |
| Volume and weight | 52inch:2480* 800* 1700mm(bare pager)2970* 940* 1900mr(wooden case) |
FAQ
Q1: What products can the GE flat knitting machine make?
A1: The GE series can make sweater panels, cardigans, pullovers, scarves, hats, gloves, blanket panels and knitted clothing accessories. The final product range depends on gauge, working width, yarn type, knitting functions and take-down configuration.
Q2: Which gauge should be used for a sweater project?
A2: Coarser gauges are commonly used with thicker wool, cashmere or acrylic yarns, while finer gauges are suited to lighter yarns and finer fabric structures. Buyers should provide the yarn count, yarn composition, sample fabric and required fabric feel so the gauge can be matched correctly.
Q3: What technical data is needed for a machine proposal?
A3: Please provide the intended product, yarn material, yarn count, required gauge, panel width, knitting pattern, number of colors, planned output, machine system, take-down method and comb requirement. Local voltage, frequency, workshop size and software needs should also be stated.
Product Advantages
1.Double-System Knitting Structure
The GE machine uses a double-system arrangement with a raised take-down roller, sinker mechanism, dynamic stitch control and motor-controlled carriage reversing. This arrangement supports sweater panels and other shaped knitwear.
2.Gauge and Working Width Choices
Published series data covers 7G, 9G, 10G, 12G, 14G and 16G gauges, together with knitting widths of 52, 60, 80 and 100 inches. The machine size can be matched with the yarn count, panel width and intended knitwear.
3.Broad Yarn Compatibility
The GE series can work with wool, cashmere, cotton, acrylic, synthetic filament, silk and blended yarns. The suitable gauge and yarn-feeding device depend on yarn thickness, elasticity and surface characteristics.
4.Pattern and Shaping Functions
Available knitting functions include knit, miss, tuck, transfer, pointelle, intarsia, jacquard and visible or concealed shaping. These functions support plain panels, ribs, cables, color patterns and shaped garment parts.
5.Digital Operation and Fault Alerts
The operating system includes an LCD screen, USB memory, pattern software and multilingual menus. Machine alerts can cover yarn breakage, yarn knots, floating yarn, needle damage, racking faults and programming errors.
