High quality Direct Fiberglass warping machine TDGA528

main feature :

The machine is designed for sectional warping of various yarns, including worsted yarn, high-twisted flaments, yarn for colorwoven fabric, silk fabric, toweling fabric, and specialty fabrics. It features constant speed winding and unreeling, thanks to our new technology, AC frequency converter speed adjustment device, which is controlled by a computer for sleepless monitoring. Additionally, we've implemented external steel strip damping to eliminate noise and uneven tension issues commonly found in traditional clamping type damping.


_0000_详情页主图

Product details

The traverse of warping operation panel is accurately controlled by servo motor.The staring point setting and stripe setting can be achieved automatically once by pressing the button.

The forward and back movement of warping operation panel is controlled by a step motor,so that the distance between space reed and yarn on drum is consultant and the distance is optional.

To keep the yarn on the drum can gain constant speed when winding and unreeling,the new technology,AC frequency converter speed adjustment device,which controlled by computer to realize the sleepless monitor,is put into practice.

The machine is braked by an electronic-mechanical-hydro-pneumatic device during warping.the beaming tension control adopted extemal steel strip damping,which eliminates the noise and uneven tension problems occured in the traditional clamping type damping.

The optional automatic power control system can be equipped according to the requirements.

Main technical parameters

Work width

(mm)

2300(Basic form)

(it can be customized )

Positioning of cone

Starting point

Automatic

Beam flange

diameter(mm)

<800 (Basic form)

Stripe location

Automatic

Warping speed

(m/min)

0-600

Stripe width(mm)

0.1-999.9 (the length

should not be longer than

the guide roller)

Beaming speed

(m/min)

0-100

Spindle space(mm)

300x250 (wool yarn/

cotton yarn)290x290,

220x220(Chemical fiber)

Deviation of linear

speed

+2%

Spindle number

392(wool yarn/cotton yarn)

480(Chemical fiber)

Braking distance(m)

≤2 (with a speed of

300 m/min)

Input voltage(V)

3x380(+10%)

Beaming tension(N)

≤6000 (Beaming

speed<50m/min)

Capacity(KVA)

30

Drum diameter(mm)

1026

Warping motor

power(KW)

7.5

Cone Length(mm)

1010

Beaming motor

power(KW)

15

Cone angle

Strip traverse motor(KW)

1.5

Stripe traverse speed(mm/r)

0.001-9.999 (No grade)

Warping and beaming

frame weight(kg)

4500

Deviation of

stripe traverse

0.02%

Creel weight(kg)

2500
