Needle type | Latch needle |
Gauge | E18 E22 E24 |
Working width | 100 inches,138 inches |
Guide Bar No. | 4 separate Jacquard looms,4 ground combs |
Double pile height | 2-12mm |
Main drive | Oil-immersed cam,Eccentric linkage |
Max speed | 500 rpm |
Pattern drive | N-pattern drive,chain link or pattern disk(Optional: Electronic Control) |
Yarn let-off device | EBC Electronic yarn let-off |
Fabric take-up | Electronic take-up |
Batching device | Independent batching device |
Main motor power | 7.5 kw |
FAQ
Q1: What fabrics can the TD-DJ6/2 Raschel machine produce?
A1: The machine is intended for patterned double-layer and spacer fabrics used in automotive seats, mattresses, sofas, curtains, clothing and footwear. Final suitability depends on the yarn, gauge, fabric density and required thickness.
Q2: What does the 2 to 12 mm double-pile height mean?
A2: The published specification lists a 2 to 12 mm distance between the two knitted fabric layers. The page should not describe this value as finished pile height unless it has been confirmed by the technical department.
Q3: What information is needed for a TD-DJ6/2 machine proposal?
A3: Please provide the fabric application, sample or photo, yarn material, yarn count, gauge, finished width, fabric thickness, fabric weight, stitch density, pattern requirements, daily working hours, voltage and frequency.
Product Advantages
1.Patterned Double-Layer Fabric Structure
The TD-DJ6/2 uses two needle beds to knit linked fabric layers. The 2 to 12 mm published range covers several spacer and double-layer fabric structures.
2.Three Gauge and Width Groups
Gauge options include E18, E22 and E24. Working widths of 100, 138 and 210 inches cover different automotive, bedding, home textile and footwear fabric plans.
3.Electronic Yarn and Fabric Handling
EBC electronic warp let-off manages yarn delivery during knitting. Electronic fabric take-up and the independent batching unit handle the knitted material after fabric formation.
4.Several Pattern Motion Methods
The machine can use an N-pattern drive, chain links or pattern discs. Electronic pattern shifting can be included when the fabric design requires lateral pattern movement.
5.Yarn Fault Monitoring and Maintenance Access
A yarn-break monitoring device can pause the knitting process after a yarn fault is detected. The swingable shaping-plate bed provides access during needle-tongue replacement and routine maintenance.
