High Speed Rapier Loom
High Speed Rapier Loom
Accurate control
Strong beating up
Super motor drive structure
Leno for selvage structure
High speed weaving
High-Speed Rapier Loom TD600
main feature :
TD600high-speed rapier velvet loom using advancedmechatronics technology,with mature and stable performancelts economic speed 250-350 RPMMax weft insertion rate is1000 meter/min,high cost performance and high speedintelligent loom.It is suitable for Cotton,Linen,wool,polvesterman-made fibers, etc.
Product details
TD600high-speed rapier velvet loom is used in Cleaning flannelette, velveteen, velvet, plush, industrial cloth and other fabrics, including sofa flannelette, car decoration flannelette, curtain flannelette, clothing velvet fabric, clothing velvet fabric, home textile velvet, light blanket, prayer blanket.
Sofa Velvet
Soft, dense velvet fabric provides a refined surface for sofas, chairs and upholstered furniture. Its consistent pile appearance and comfortable texture make it suitable for residential furniture, hotel seating and interior decoration.
Car Decoration Velvet
Velvet fabric for automotive interiors combines a neat surface with practical wear performance. It can be used for seat covers, door panels, roof linings and other interior trim requiring comfort and a consistent fabric structure.
Curtain Velvet
Dense velvet curtain fabric offers an elegant drape and rich visual texture. It is suitable for homes, hotels, theatres and commercial spaces requiring decorative curtains with a soft and refined appearance.
Clothing Velvet Fabric
Smooth, fine-pile velvet adds softness, depth and a refined finish to garments. It is widely used for dresses, jackets, formalwear, fashion accessories and other apparel requiring a distinctive surface texture.
Prayer Blanket
Soft velvet fabric with a neat pile surface is suitable for prayer rugs and lightweight prayer blankets. Its comfortable texture and decorative appearance meet the requirements of daily use and various interior styles.
Main technical parameters
| Nominal reed width | 190,230,260,280,320,340(cm) |
| Loom speed | Design speed500 RPM, Optimal speed 250-350 rpm |
| Piling height | 0--10(mm) |
| Suitable Yarn | Cotton 3-80s， Filament 20-1000D，Man-made fiber 5-500Tex |
| Main drive | High Power Asynchronous Motor Drive,stepless speed change by inverter |
| Pile feeding | Optional mechanical feeding device or servo electronic feeding device |
| Shedding | Electronic Dobby,with levers up to 20 pcs |
| Beating up | Double-side driv e, conjugate cam beating-up mechanism |
| Weft insertion | Space four-bar linkage drive, single cloth- fell weft insertion device |
| LET OFF | Servo Electronic Let off |
| TAKE UP | Servo Electronic take up |
| Pick finding | Slow motion Automatic pick finding Device |
| Color selecting | Electronic color selection device, up to 8 colors |
| Warp beam | Ground beam 中800mm,Pile beam 中800 or 1000mm |
| Batching | Outer double Batching device,Max800for each batching device |
| Weft control | Electronic weft detector high sensitivity. anti-double weft, up to 8 colors |
| Warp Stop device | electronic warp stop device |
| Lubrication device | closed cycle lubrication device. Equipped with oil pressure and oil level alarm device |
| Selvage formation device | Independent electronic LENO device |
| Optional device | electronic Selvage jacquard device, Hot-melt Selvage device, etc |
Q1: What fabrics can the TD600 rapier velvet loom weave?
A1: The TD600 can weave velveteen, velvet, plush, cleaning flannelette, sofa velvet, curtain velvet, clothing velvet, vehicle interior fabric, light blankets and prayer blankets. Final machine planning depends on the yarn, pile height, fabric width, density and pattern.
Q2: What are the speed and pile height ranges of the TD600?
A2: The published design speed is 500 rpm, while the stated operating range is 250 to 350 rpm. Pile height can be adjusted within 0 to 10 mm. Actual speed depends on reed width, yarn condition, pile structure and fabric density.
Q3: What information is needed for a TD600 machine proposal?
A3: Please provide the fabric name, ground yarn, pile yarn, weft yarn, finished width, fabric weight, warp density, weft density, pile height, weft colours, pattern and planned output. Local voltage, frequency, workshop temperature and roll diameter should also be provided.
1.Multiple Velvet Fabric Applications
The TD600 is arranged for cleaning flannelette, velveteen, velvet, plush and other pile fabrics. It can also be planned for sofa fabric, vehicle interior fabric, curtain velvet, clothing velvet, home textiles, light blankets and prayer blankets.
2.Adjustable Pile Height
Pile height can be set within 0 to 10 mm. Mechanical pile feeding or servo electronic pile feeding can be arranged according to the yarn and fabric structure.
3.Mechanical Rapier Transfer
A spatial four-bar rapier drive carries the weft yarn, while a double-sided conjugate cam unit controls beating. This mechanical weft transfer supports cotton, filament and man-made fiber yarns.
4.Pattern and Weft Colour Options
An electronic dobby with up to 20 levers supports different fabric structures. The electronic colour unit handles up to eight weft colours for velvet and decorative fabrics.
5.Electronic Warp and Cloth Control
Servo electronic let-off and take-up coordinate warp tension and cloth movement. The external double batching arrangement supports rolls up to 800 mm at each winding position.
