| Model | TDHKS-4M |
| needle | Compound groove needle |
| needle number | E24 |
| mm width | 186” | 220” | 242” | 280” |
| guide bar | 4pcs |
| max speed(rpm) | 1500 |
| 1400 | 1350 |
| moving system | (EL)Ntype pattern cam or EL electronic control system |
| let-off system | BC or EBA electronic let-off system |
| take-up system | Electronic brushing take-up |
| beam spec | φ535×535(φ21”×21”),Φ765×535(φ30”×21”)φ1016×535(φ40×21) |
| main motor power | 5.5kw | 5.5kw | 7.5kw |
| let-off motor power | / | / | 4-1.5KW | / |
| Electronic draw-off motor power | / | / | 1.5KW | / |
| slow moving motor | / | / | 0.75kw | / |
| Brushing motor power | 1.5KW | 1.5KW | 2KW |
| Crankshaft connection rod lubrication | Initiative pressing lubricate andoil circulation constant temperature controlsystem |
FAQ
Q1: What products can the TDHKS4M-TJ machine make?
A1: The machine can make patterned warp-knitted terry fabric for microfiber towels, car cleaning cloths, kitchen wipes, sports towels, bath textiles and other home-textile products. The suitable product range depends on the yarn and machine plan.
Q2: Can this machine make conventional cotton bath towels?
A2: The machine is mainly intended for warp-knitted terry made with microfiber, filament yarn and approved blends. Conventional cotton terry towels are normally produced on towel weaving looms. A cotton application should undergo a fabric trial before the machine plan is confirmed.
Q3: What information is needed for a machine proposal?
A3: Please provide the yarn material, yarn count, fabric width, fabric weight, terry side, loop height, Jacquard pattern, planned daily output, local voltage and workshop size. A finished fabric sample or towel specification is also helpful.
Product Advantages
1.Electronic Jacquard Pattern Control
The electronic Jacquard arrangement manages programmed terry patterns during knitting. It supports different visual designs according to the confirmed fabric plan.
2.Single-Sided and Double-Sided Terry Options
The machine can be prepared for different terry surface structures. The suitable arrangement depends on the yarn, loop design, fabric weight and finished product.
3.Microfiber Yarn Applications
The machine can process approved polyester microfiber, polyamide, nylon, acrylic, spandex and blended yarn plans. Yarn suitability should be checked through a knitting trial.
4.Multiple Finished Products
The knitted terry fabric can be used for car cleaning towels, household cloths, kitchen wipes, sports towels, bath textiles and other cleaning or home-textile products.
5.Coordinated Yarn and Fabric Handling
Warp delivery, loop formation, fabric take-up and batching are planned as a connected knitting process. Machine settings can be prepared according to fabric width, weight and terry structure.
