R456 ROTARY SCREEN DRYER

FAQ

Q1: What materials can the R456 Rotary Screen Dryer process?

A1: Public TONGDA information references viscose fiber, cotton, linen, wool and chemical fiber materials. The final material range should be checked according to fiber structure, moisture level and process conditions.

Q2: What is the effective working width of the R456?

A2: Public TONGDA material lists an effective working width of 1800 mm. The current export configuration should be confirmed before the figure is used in a project specification.

Q3: What information is needed for an R456 quotation?

A3: Please provide fiber type, initial moisture, target moisture, feed rate, daily output, working width, heat source, exhaust conditions, electrical supply and workshop dimensions.

Product Advantages

1. 1.Radio Frequency Heating Within Yarn Packages

RF energy acts on moisture inside the yarn package rather than relying only on surface heating. This method supports moisture movement across the package core and outer layers.

2. 2.Continuous Post-Dyeing Drying Process

The conveyor arrangement permits dyed yarn packages to pass through the drying chamber in a continuous process after hydro extraction.

3. 3.Published Capacity for Several Yarn Groups

Public TONGDA data list 760-920 kg/h for synthetic yarn, 305-350 kg/h for wool and cotton blends, and 170-210 kg/h for cotton and viscose yarn.

4. 4.TDA01-85 RF Power Configuration

The listed TDA01-85 configuration uses 85 kW RF output power. The final production rate should be checked against package density, moisture level and yarn composition.

5. 5.Process Matching for Yarn Package Data

Drying settings can be prepared according to cone type, package diameter, package height, yarn regain and target moisture. This helps align the machine plan with the actual dye-house process.
