Sliver Lap Former FA360

main feature :

The Silver Lap Former FA360, equipped with fully electric, automatic, and interactive systems, ensures precision, efficiency, and high yield during production.

-2_0000_360b
-2_0001_2

Product details

1.The machine adopts the large color touch screen(imported) to realize man-machine communication. It makes operation and maintenance of machine easier, convenient and operator-friendly.

2.The machine adopts the programmable controller to control the machine operation. The inverter is used on main motor. The whole operating process is easy, convenient, stable and reliable.

3.Operator-friendly design eases operation. There are inching, start, and stop buttons on the pneumatic box at the front head of the machine, and on top of the electric control panel at mid section of the machine.

4.It adopts inverter motor drive to facilitate stable startup, high efficiency and energy saving.

5.3-over-3 drafting system with pneumatic weighting is adopted. According to the batt weight required, the main draft times can be set. The pneumatic weighting mechanism is simple, stable and reliable.

6.Elevated feed creel is used, with sliver cans placed on both sides of the lap table. The direction of lap drafting is in accordance with that of the lap table, with sliver entering into drafting system free of twists and turns.

Main technical parameters

No. of feed slivers

18-28

No. of drafting heads

2

Weight of feed sliver

20-28g/5m

Batt weight

60-80g/m

Suitable Length

cotton

Max. lap diameter

650mm


300mm


about 25kg

Speed

80-135

Max.yield

500kg/h

Drafting type

3 over 3

Drafting times

1.31-3.10、1.27-2.42

Pneumatic

Pneumatic weighting

Draft zone distance

42-48mm(HV)、45-51mm(VV)

Candiameter

dia600mm or 1000mm

Motor power

11kw

Compressed air

0.7-0.8Pa, air cosumption

Exhaust air

The central collective suction or standalone suction

Amount of exhaust air

2200
