TD-DBA HYDRAULIC BALING MACHINE
main feature :
Hydraulic four-open door, single-side wire feed, can be added with outer wrapper while compressing bags, fast speed of packing, is a special type for velveteen bale, economical and practical, easy maintenance, and fine appearance.
Product details
Mainly used for the compression packing of cotton,cashmere, wool, blankets and other soft articles.
Main technical parameters
| Item | TD-DBA125J | TD-DBA125B | Remarks |
|---|---|---|---|
| Bale Size (mm) | 1000 × 500 × 1000 | 1000 × 500 × 800 | Customizable |
| Bale Weight (kg) | Approx. 120 | 70–150 | Cotton |
| Rated Working Pressure (MPa) | 15 | 15 | — |
| Baling Pressure (MPa) | 12 | 11 | — |
| Motor Power (kW) | 15 | 7.5–15 | — |
| Cylinder Stroke (mm) | 1400 | 1400 | — |
| Dimensions L × W × H (mm) | 2600 × 1800 × 4800 | 2600 × 1600 × 4800 | L × W × H |
| Machine Weight (kg) | 3000 | 2800 | — |
Q1: What materials can the TD-DBA hydraulic baler process?
A1: The machine is intended for cotton, cashmere, wool, blankets and other soft textile articles. Material bulk density, moisture level and the required bale dimensions should be confirmed before machine planning.
Q2: What is the difference between the TD-DBA125J and TD-DBA125B?
A2: The TD-DBA125J has a bale chamber of 1000 × 500 × 1000 mm and an approximate cotton bale weight of 120 kg. The TD-DBA125B has a 1000 × 500 × 800 mm chamber and a listed cotton bale weight of 70 to 150 kg.
Q3: What details are needed for a baler proposal?
A3: Please share the material type, moisture level, bulk density, target bale size, bale weight, bales per hour, wire type, wrapping method, local voltage and factory height. Middle East projects should also state the room temperature, hydraulic oil plan and available floor space.
Product Advantages
1.Four-Door Bale Chamber
The chamber uses four opening doors, giving operators access to the bale after compression. This arrangement assists outer wrapping, wire placement and bale removal.
2.Two Bale Formats
The TD-DBA125J has a chamber size of 1000 × 500 × 1000 mm and forms an approximate 120 kg cotton bale. The TD-DBA125B uses a 1000 × 500 × 800 mm chamber and covers a listed cotton bale weight of 70 to 150 kg.
3.Hydraulic Compression Data
Both models have a rated working pressure of 15 MPa and a cylinder stroke of 1400 mm. Published baling pressure is 12 MPa for the TD-DBA125J and 11 MPa for the TD-DBA125B.
4.Wire and Outer Wrapping
The machine uses single-side wire feeding and can work with an outer wrapper during bale preparation. Binding materials can follow the planned storage and transport method.
5.Soft Textile Material Range
The machine can bale cotton, cashmere, wool, blankets and other soft articles. Final machine settings should match material bulk density, moisture condition and the required bale weight.
