TD211W HIGH TEMPERATURE HIGH PRESSURE BEAM DYEING MACHINE
main feature :
TD211W HIGH TEMPERATURE HIGH PRESSURE BEAM DYEING MACHINE uses a head tightening mechanism and, with the main pump and dye circulation, can achieve uniform dyeing.
Product details
Widely adaptable, suitable for nylon, polyester fibers, trilobal bright yarn, oxford cloth, elastic fabrics, lace, and knitted fabrics, it can also handle special industrial fabrics and high-density plain fabrics.
Main technical parameters
| Model | Max. working pressure(bar) | Working temperature(℃) | Main pump power(KW) | Main tank dia.(mm) |
| TD211W-50 | 5 | 140 | 30 | 500 |
| TD211W-70 | 5 | 140 | 37 | 700 |
| TD211W-105 | 5 | 140 | 45 | 1050 |
| TD211W-120 | 5 | 140 | 55 | 1200 |
| TD211W-140 | 5 | 140 | 75 | 1400 |
Q1: What materials can the TD211W beam dyeing machine process?
A1: The published application range includes nylon, polyester fiber, Oxford cloth, elastic fabric, lace, knitted fabric, industrial textiles and high-density plain fabric. Fabrics made with trilobal bright yarn can also be evaluated. Actual compatibility depends on the material construction, width, density, stretch and dyeing recipe.
Q2: Which TD211W model sizes are available?
A2: The series includes TD211W-50, TD211W-70, TD211W-105, TD211W-120 and TD211W-140. Their main tank diameters are 500, 700, 1050, 1200 and 1400 mm. All five models are listed at 140°C and 5 bar, with main pump ratings of 30, 37, 45, 55 and 75 kW.
Q3: What information is needed for a TD211W technical proposal?
A3: Please provide the fabric type, fiber content, construction, width, GSM, roll diameter, beam dimensions, planned batch weight, dye chemistry, process temperature and required output. For Middle East installations, also provide voltage, frequency, steam source, water quality, cooling-water conditions and factory layout.
Product Advantages
1.140°C and 5 Bar Working Conditions
All five published models are rated for a working temperature of 140°C and pressure of 5 bar, covering common HTHP dyeing duties for polyester and other listed textile materials.
2.Five Main Tank Diameter Options
The series includes 500, 700, 1050, 1200 and 1400 mm main tank diameters. This model range helps mills match the machine size to their beam and production plan.
3.Pump Power Matched to Model Size
Main pump ratings are 30, 37, 45, 55 and 75 kW across the TD211W range. Buyers can compare pump rating, tank diameter and planned material load during project review.
4.Broad Fabric Application Range
The published material range includes nylon, polyester fiber, Oxford cloth, elastic fabric, lace, knitted fabric, industrial textiles and high-density plain fabric. Fabrics made with trilobal bright yarn can also be assessed.
5.Head-Tightening and Liquor-Circulation Arrangement
The head-tightening mechanism works with the main pump and dye-liquor circuit to keep the load in position and promote liquor passage through the textile material.
