Water jet loom
High-Performance-Weaving-machine
Enhances the stability and aseismicity of the machine
Ensures high-quality fabric production
High-speed and stable weaving of fabric
TDW881WATER JET LOOM
main feature :
TDW881design based onTDW851 series water-jet loom, which is optimizing the main component and frame structure, improving the beating-up.let-offmechanism and take up mechanism, installing assistant device onlet-offmechanism,all of this ensure the running stably and reduce vibra.tion and noise,increase effciency and enlarge the weaving range.
Product details
TDW881design based onTDW851 series water-jet loom, which is optimizing the main component and frame structure, improving the beating-up.let-offmechanism and take up mechanism, installing assistant device onlet-offmechanism,all of this ensure the running stably and reduce vibra.tion and noise,increase effciency and enlarge the weaving range.
Main technical parameters
| Type | TDW8100 | TDW718 | TDW508 | TDW881 | TDW851 | |
| Reed space(cm) | 150,170,190,210,230,260,280,320,340,360(cm) | |||||
| Useful reed space(cm) | Maximum reed width = reed width, minimum width reed, door wiidth = reed -60cm | |||||
| Frame | Both sides of the box (the main transmission part of oil bath lubrication)+intermediate beam structure | |||||
| Driving | Brake | Direct stop mechanism by an electromagnetic brake | ||||
| Control | Push and touch button(Arrange,run,stop,forward inching) | |||||
| Motor | Rush start motor | |||||
| Motor capacity | 1.5kw 1.8kw 2.2kw 2.7kw 3.2kw 3.7kw 4.5kw 5.2kw 7.2kw 7.5kw | |||||
| Beating | Crank rocker mechanism | |||||
| Let-off | System | Automatic mechanical and continuous let-off,or electronic let-off. One or vertical two roll | ||||
| Warp beam | φ800mmFlange φ914mmFlange φ1000mmFlange | |||||
| Take-up | System | Mechanical or electronic continuous take-up | ||||
| Pick density | Normal:5-60picks/cm,special:3-70picks/cm | |||||
| Cloth width updiameter | φ520mm,Outer coil 600mm package (optional)Maximum 800mm | |||||
| Shedding | Plain shedding | Crank shedding(heald frame number:2 to 8)1/1 fabric | ||||
| Cam shedding | Cam shedding(heald frame number:2-10),plain,twill,satin fabric | |||||
| Dobby shedding | Positive/negative heald frame number:16(max),electronic and mechanical reading system,plain,twill,satin or complex deaign | |||||
| Jacquard | 1408 2688 5120 lifting hooks,electronic jacquard device | |||||
| Weft insertion | Measuring &storage | 300 TDP type mechanical measuring turbo blower (single nozzle)or electronic weft feeder(1-6nozzles) | ||||
| Pump | Type MS,MH,single pump or double pump structure | |||||
| Plunger Of Pump | Φ32/φ17,φ32/φ18,φ36/φ20,Φ36/φ22,φ36/φ24,φ36/φ26 φ39/φ28,φ39/φ30,φ42/φ32,ceramic plunger | |||||
| Nozzle Needle | T20/10,T30/10,T45/20,TL50-00,TL65-20,TL75-40,T75-40, TL90-40 | |||||
| Weft Filling | One,two,three,four nozzle,six nozzle | |||||
| Filling Feeler | Photoelectric weft feeler,Fiber type | |||||
| Selvage | Planetary gear hemming | |||||
| Electrical part | Domestic or imported | Main control board,AC contactor,transformer,Frequency converter, NC interface,selvage break system,waste yarn break system, overheating and overload protection | ||||
| Electronic meter | Count and display:rotational speed,total yield,team yield,total efficiency,team efficiency,cloth length auto control,stopping. | |||||
| Other devices | A cloth roller,a weft density gear,a trashcan,a set of nozzle needle | |||||
Q1: What fabrics can the TDW881 water jet loom weave?
A1: The TDW881 is mainly used for polyester, nylon and other hydrophobic synthetic filament yarns. Typical applications include smooth woven fabrics, lining fabrics, home textile fabrics and selected industrial textile materials.
Q2: What are the main weaving specifications of the TDW881?
A2: The available reed space includes 170, 190, 210, 230, 260, 280, 340 and 360 cm. The published weft density range is 5–60 picks/cm, with a maximum listed loom speed of 1200 rpm and a maximum weft insertion rate of 2280 m/min. The actual working speed depends on yarn, fabric construction and machine configuration.
Q3: What information should be provided before ordering a TDW881?
A3: Please provide the fabric type, warp yarn, weft yarn, yarn count or denier, finished fabric width, warp density, weft density, number of weft colors, shedding method and expected production output. For Middle East projects, please also provide the local voltage, frequency, water source, water filtration conditions and workshop dimensions.
1.Reinforced Machine Frame
The TDW881 uses a widened middle plate and reinforced crossbeam structure to increase the frame support area. The structure is designed for continuous weaving of synthetic filament fabrics.
2.Improved Weft Beating Structure
The beating-up system has been revised together with the main moving parts. The structure supports controlled weft placement and is suitable for fabrics with higher weft density requirements.
3.Continuous Warp Let-Off and Take-Up
The loom uses continuous warp let-off and take-up systems. An additional warp let-off device helps manage warp yarn movement during the weaving process.
4.Multiple Weft Insertion Options
TDW881 supports different weft insertion arrangements, including single, double, three, four and six nozzle configurations. The choice depends on weft yarn type, color quantity and fabric construction.
5.Wide Fabric Range
Reed space options cover 170, 190, 210, 230, 260, 280, 340 and 360 cm. The loom can be arranged for polyester, nylon and other hydrophobic filament yarns used in apparel, home textile and industrial fabric production.
