TD-328 Type Wire Dividing Warping Machine
main feature :
TONGDA wire dividing warping machine ensures stable operation and uniform tension for dividing and warping multi-end yarns before weaving or warp knitting.
Product details
Product Overview
TD-328 type wire warping machine is suitable for wire (polyester, nylon and other materials) high performance warper.
Single strand wire consists of a plurality of filaments, the machine can greatly reduce customer costs of raw materials and production sites, improve production efficiency.
This machine is mainly composed of a yarn frame, a yarn guide device, Zhang Ligun, wire board, wire balance roller, monofilament warp up front.
Share of wire alone has a certain torque motor given initial tension; keep the tension by the tension roller; wire board for wire drawing; and control the balance of tension traction roller on silk filament; finally by the front of constant velocity winding.
The linear speed of the whole process is constant, the tension is controllable and the tension is even.
CHARACTERISTIC
1. The new aircraft, the intelligent recognition of man-machine interface, a variety of data automatic storage;
2. Synchronous motor, speed tracking servo control, automatic control detection mechanism;
3. Computer real-time detection, intelligent control of tension;
4. Pan head loading pneumatic control, linear lifting, stable motion, accurate positioning;
5. The spindle brake pneumatic control, quick and reliable braking;
6. Warping tension uniformity, tension fluctuation is small, flat beam;
7. Online speed, with different speed, different roll diameter braking curve, ensure smooth parking yarn.
Main technical parameters
Application | 21×30,21×21(inch) |
Wire separately | 720 heads(customizable) |
Warping speed | 650m/min |
Active yarn creel | 72 wire strands;single strand torque motor control |
Balance roller | 2 sets |
Stop device | Drop stop |
Main motor power | 7.5kW AC variable frequency control
|
Control mode | Computer real-time control,touch screen man-machine interface |
Q1: Does the TD-328 process metal wire?
A1: No. The word “wire” in the original product name refers to polyester, nylon or another approved multifilament yarn. The machine separates a multifilament strand into individual filament ends and winds them onto a warp beam.
Q2: What are the main working specifications of the TD-328?
A2: The published machine data lists a 72-strand active creel, up to 720 divided filament ends, two balance rollers, a warping speed of 650 m/min and a 7.5 kW AC main motor. Listed beam formats include 21 × 30 and 21 × 21 inches. Final beam dimensions should be checked against the buyer’s beam drawing.
Q3: What details are needed for a TD-328 machine proposal?
A3: Please provide the yarn polymer, incoming yarn denier, filament quantity in each strand, target filament denier, total running ends, package dimensions, warp beam drawing and planned operating speed. Please also provide the factory voltage, frequency, air conditions, ambient temperature, workshop dimensions and destination country.
1.Filament Splitting and Beam Winding
The TD-328 separates multifilament yarn into individual filament ends and winds the divided ends onto a warp beam. This arrangement combines two related working stages in one machine process.
2.Individual Creel Tension Control
The active creel carries 72 multifilament strands. Each strand has torque-motor control for initial tension, helping the machine manage yarn movement before filament separation.
3.Up to 720 Divided Filament Ends
The published arrangement supports up to 720 divided ends. The working end quantity should match the filament count in each incoming strand and the warp beam specification.
4.Two Balance Rollers
Two balance rollers assist tension management between the separation area and the beam winding section. Constant linear winding supports an even yarn path during machine operation.
5.HMI and Pneumatic Beam Handling
The touch-screen HMI displays operating values and supports machine monitoring. Pneumatic beam loading, linear lifting, positioning and spindle braking assist daily beam handling.
